Desktop Electrode Hydraulic Dry Pressing Machine

Max. Pressure

8 metric tons Max.
Pressure gauge is built in

Gauge Pressure Value to Force Conversion

• Notes:
• Displayed Pressure Value to Actual Applied Force Conversion: 1 MPa = 0.6 Ton
• The actual force applied on the Hydraulic Cylinder (Ton) equal to the force applied on your working piece
• For calculating the actual pressure (MPa) applied on your working piece, please follow the equations in below:

          P = T/(πr^2) x g x 10

• P: Pressure (MPa) applied on your working piece
• T: Force (Ton) applied on the Hydraulic Cylinder
• g: Standard gravity. g ≈ 9.8 m/s2
• π: ~3.14
• r: Radius (cm) of the working piece
• *1 Metric Ton = 1000 kg; 1 MPa ≈ 10 kgf/cm2

Pump

Build-in Hydraulic Pump

Warranty

Two year limited manufacturer warranty with lifetime support.

Bottom Hydraulic Cylinder Travel Distance

Standard 30mm, opitional other distance

Dimensions of Machine

230mm X 200mm X 330mm

Compliance

CE Certified

Net Weight

30 kg

Press Dies

Pressing dies with various diameters are available upon request
