5 Channel Automatic Battery Sorter Sorting Machine for Cylindrical Cell

  • Model Number:

    TMAX-FN-5
  • Type:

    Automatic
  • Input Power:

    900w
  • Dimension(L*W*H):

    1120*880*1250
  • Net Weight:

    200kg
  • Compliance:

    CE Certified
  • Warranty:

    two year warranty,one stop service,provide full solutions
  • Place of Origin:

    China
  • Update:

    Optional
  • :

    Xiamen
  • Payment:

    L/C D/A D/P T/T Western Union
  • Delivery Time:

    3 days
contact now
DESCRIPTION

    5 Channel Automatic Battery Sorter Sorting Machine for Cylindrical Cell

Features:

1. It is a must equipment for Battery Pack Manufacturer for voltage and resistance testing and sorting

2. 5 Channel automatic cell sorter is designed to sort cylindrical 18650 or 26650 cells

3. Sort by cell's voltage and impedance up to 5 groups

4. Automatic sorting control

5. Fast sorting speed (80PPM)

6. Easy to refill cells during the process

7. Wheels design, easy to move the machine to any operating place

Specifications:

Model




TMAX-FN-5



Voltage supply



220V/50HZ( no need air supply)



Power



<900w



Display screen





Large size LCD screen/Touch screen




Suitable for









18650 battery


Net Weight


<200KG



Internal resistance test



Test range:80mΩ

Accuracy:±0.015% rdg

Resolution:0.01Mω


Dimensions

1120*880*1250


Voltage test



Test range0-8V

Accuracy:±0.5% rdg

Resolution:0.01mV



Sorting speed



80PPM



battery sorting machine

battery sorter

battery sorter

battery sorting machine

battery sorting machine

 battery equipment


1.  We supply machines with battery technology support.

2.  We supply full set of lithium battery equipment for lab research, pilot scale research and production line.



1 Standard exported package : Internal anticollision protection, external export wooden box package
2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode
3 Responsible for the damage during shipping process, change the damage part for free
4 Supply with suitable voltage input and power plug according to customer's country requirements.
5 Supply with CO, ECO, FORM A, FORM E and any other original certificate for import custom clearance and tax relief.
