Electric Coin Cell Disassembling Machine

Power

110 - 240V AC 50/60Hz for universal use

24V DC motor with reducing gear, 20W

Die Set & Compatibility

Disassembling dies for disassembling CR2032, CR2025, & CR2016 coin cells (Optional CR2325, CR2450 die sets are available upon request).

Pressure

1. The pressure applied to seal the cell case is pre-set to a constant pressure at about 800 kg before shipping.

2. Pressure adjustment knob at the top can be used to adjust the pressure applied to the negative cap of the cell  to prevent case deformation.

Structure

Heavy Duty Steel Platform

Protection Shield

Protection shield / enclosure (plexiglass) with safety interlock is installed

Product Dimensions

250mm(L) x 150mm(W) x 450mm(H)

Compliance

CE

Warranty

Two years limited warranty with lifetime support

Maintenance Notes & Warnings

1. Electrolytes are highly corrosive materials.The die set must be cleaned with alcohol after each use to avoid corrosion

2. The PTFE die (found at the top die) ejects the cell casing after crimping via spring loaded pressure. Do NOT over tighten the pressure adjustment knob to avoid damaging this PTFE die.

3.To set the proper pressure on the die, loosen the knob all the way until the spring compression is no longer stressed. Then start tightening the knob and stop turning it once the spring compression is felt.

4.This will prevent the PTFE die from becoming deformed by being subjected to excessive pressure.

Net Weight

32 kg

Shipping Weight

46 kg
