Lab 10 - 800 mm Adjustable Electrode Film Coating Machine for Cylindrical Cell Research with Dryer

  • Model Number:

    TMAX-VFC-150B
  • Input Power:

    680W
  • Dimension(L*W*H):

    10 - 800 mm adjustable
  • Net Weight:

    About 68kg
  • Compliance:

    CE certificate
  • Warranty:

    Two Year limited warranty with lifetime support
  • Delivery Time:

    3 Days
contact now
DESCRIPTION

Lab 10 - 800 mm adjustable Electrode Film Coating Machine for Cylindrical Cell Research with Dryer

DESCRIPTION

The TMAX-VFC-150B Film coating machine with dryer is used for varies kinds of materials coating.

It is supplied with vacuum pump and heating system, having an precision heating temperature up to 200°C.

The film coating machine is mainly used for lithium battery electrode coating for coin cell assemble and pouch cell research.

Machine model

Film Coating Machine  TMAX-VFC-150B

Source voltage

AC110V-240V, 50/60HZ

Power

680W

Coating speed

0-100mm/s, Step-less transmission   Accuracy: 10mm/sec

Advantages

Supply with dry function, vacuum pump

Stroke length

10 - 800 mm adjustable by using Adjustable Position Switch

Platform

Aluminum alloy flat vacuum chuck

Vacuum Chuck Dimensions: 368mm(L) * 200mm(W)*30mm(T)

Slicker width

0-150mm

 Slicker adjustable range

0.01-3.6mm

Heating dry system

RT-200°C, Digital temperature controller

Temperature control accuracy

±1.5°C

Dimension

550*330*340mm

Weight

About 68kg

Warranty

Two Year limited warranty with lifetime support

Reference Pictures

1 One oil-less vacuum pump is included for immediate use

2 Heating system : Installed on the top cover

Built in digital temperature controller with accuracy of +/-1°C

Suspension support helps open cover easily and safely.

Max. Heating Rate:10°C/min

Max. Heating Temp.:200°C

3 One 150mm width micrometer adjustable film applicator is included

Traverse Pusher is included for pushing the Film Applicator to ensure

the constant coating speed



                    Electrode Coater

                 Electrode Coater

                    Electrode Coater

                       Electrode Coater

                    Electrode Coater

                    Electrode Coater


 battery equipment


1.  We supply machines with battery technology support.

2.  We supply full set of lithium battery equipment for lab research, pilot scale research and production line.



1 Standard exported package : Internal anticollision protection, external export wooden box package
2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode
3 Responsible for the damage during shipping process, change the damage part for free
4 Supply with suitable voltage input and power plug according to customer's country requirements.
5 Supply with CO, ECO, FORM A, FORM E and any other original certificate for import custom clearance and tax relief.
