Large Heating Roller Press Machine Calender For Li ion Battery Production Line

  • Model Number:

    Tmax-rolling1
  • Compliance:

    CE Certified
  • Warranty:

    Two years limited warranty with lifetime technical support
  • Payment:

    T/T, Credit Card, Paypal, LC, Western Union
  • Delivery Time:

    3 days
contact now
DESCRIPTION



Large Heating Roller Press Machine Calender For Li ion Battery Production Line



Characteristics of equipment:

TMAX rolling1 adapt to continuous rolling process for all kinds of lithium battery anode and cathode.

1.   Rolling speed: 2~12r/pm, CVT adjustable.

2.   Roller material: 9 Cr2Mo, Roller surface hardness: HRC 65~68

3.   Gap adjustment method: Servo motor drive the middle wedge to adjust, mechanical self-locking.

4.   Roller gap adjustment range: 0~2mm

5.   Roller gap adjustment accuracy:1μm

6.   Thickness uniformity of pole sheet after rolling: ≤±2μm. Maximum rolling form:3000 KN


 Specifications of roller:


Item Type

RM500

RM600

RM800

Roller size

500*500mm

600*600mm

800*800mm

Pole sheet width

200~500mm

200~550mm

300~750mm

Output speed

2~11rpm

2~10rpm

3~12rpm

Roll straightness speed

4~17m/min

4~19m/min

6~30m/min

Roller surface roughness

Ra≤0.2

Ra≤0.2

Ra≤0.2

Roll cylindrical degree

≤2.0μm

≤2.0μm

≤2.0μm

Roll thickness accuracy

±2.0μm

±2.0μm

±2.0μm

Roll pressure range

100~300t

100~300t

100~300t

Roll gap adjustment range

0~2.0mm

0~2.0mm

0~2.0mm

Roll gap adjustment accuracy

1μm

1μm

1μm

Tension adjustment range

2.2~20kg

2.2~20kg

2.2~20kg

Orderly winding error

±0.5mm

±0.5mm

±0.5mm

Retractable roll diameter

Max:Ø550mm

Max:Ø550mm

Max:Ø550mm

Air pressure

0.5MPA above

0.5MPA above

0.5MPA above

Power

15KW

18KW

35KW
