Planetary Vacuum Centrifugal Mixer With Two 300 ML Containers for Lithium Battery Research

  • Model Number:

    MSK-PCV-300-LD
  • Type:

    Planetary Mixer Machine
  • Dimension(L*W*H):

    400 mm x 590 mm x 580 mm
  • Net Weight:

    90 kg (200 lbs)
  • Compliance:

    CE certificate
  • Warranty:

    2 Years with lifetime support
  • Delivery Time:

    3 days
contact now
DESCRIPTION

Planetary Vacuum Centrifugal Mixer With Two 300 ML Containers for Lithium Battery Research


The planetary centrifugal vacuum mixer MSK-PCV-300-LD is designed for mixing and deaerating various kinds of liquid, slurry, paste, and powder materials. It could be used for mixing and homogenizing nanopowders, nanotubes, ceramics powders, battery powder/slurry, metal powders, and especially high viscosity slurry/paste. The vacuum mixing capability is integrated for best mixing results. The standard package includes two 300 mL containers and counter-weights. High-throughput adapters are also available for 6 samples (7 ml per sample) mixing per batch.


SPECIFICATIONS

Features

·         Compared with other brands of the planetary centrifugal mixer, MSK-PCV-300 has the following unique features:

o    Mixing under vacuum for deaeration

o    Dual containers for larger quantity

o    Minimized contamination (no metal mixing blade)

o    Low cost

·         Sample Materials

o    Nanopowders, ceramic powders

o    Grease

o    Slurry

o    Paste

Voltage Input



Single Phase AC 208 - 240V, 50/60 Hz

Power

·         Maximum: 1500 W

·         Motor Power: 750 W

Mixing



·         Planetary Centrifugal Vacuum Mixing

o    The centrifugal force of rotation and revolution induces convection, homogenizing the materials

o    With the vacuum pressure, submicron air bubbles can be efficiently eliminated from the materials

Vacuum Capability



·         Pumping Rate: 165 L/min

·         Ultimate Vacuum: -95 kPa

·         Built-in vacuum pump with integrated control

Speed



·         Sample Platen Rotation (revolution motion):600 rpm - 2,000 rpm (adjustable)

·         Container Spin (rotation motion):360 rpm - 1,200 RPM (fixed at 0.6X of the revolution speed)

·         Customized ratio between revolution and rotation is available upon request at extra cost

Containers and Counter-Weights



·         Two standard containers and counter-weights are included

o    Two 300 mL containers with gas vent, made of high-density Polyethylene

o    Counter-weights (10, 20, 50 g) with adapter, made of high-density Polyethylene

Max. Mixing Volume and Weight





Container

Max Sample Volume

Max Sample Weight

Max Gross Weight (Container Included)

300 mL

150 mL

140 g

200 g

100 mL

50 mL

45 g

·         80 g (adapter not included)

 30 mL

15 mL

12 g

20 g (adapter not included)

·         Attention: Sample overload might damage the motor and/or cause spilling. Follow both the volume and weight limit when loading.

Program



·         Store up to 6 programs in memory, as shown in Fig.1

·         3 programmable segments, as shown in Fig.2. For example:

o    800 rpm revolution speed (480 rpm rotation speed) for 60 sec;

o    1500 rpm revolution speed (900 rpm rotation speed) for 180 sec;


o    1000 rpm revolution speed (600 rpm rotation speed) for 60 sec.

·         Maximum running time for each segment is 200 sec. Maximum total running time is 600 sec

·         The rotation direction could be either clockwise (mode A) or counter-clockwise (mode B)

Safety and Protection



·         Safety warning and interlocks are integrated. The unit automatically stops when

o    The unit is overloaded with the sample

o    The sample is loaded in an unbalanced way

o    The top cover is opened

Dimension



400 mm (W) x 590 mm (H) x 580 mm (D)

Weight



90 kg (200 lbs)



                Planetary Centrifugal Mixer




 battery equipment


1.  We supply machines with battery technology support.

2.  We supply full set of lithium battery equipment for lab research, pilot scale research and production line.



1 Standard exported package : Internal anticollision protection, external export wooden box package
2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode
3 Responsible for the damage during shipping process, change the damage part for free
4 Supply with suitable voltage input and power plug according to customer's country requirements.
5 Supply with CO, ECO, FORM A, FORM E and any other original certificate for import custom clearance and tax relief.
