Cylindrical Battery Semi-Automatic Adjustable Electrode Slitter Machine For Coated Electrodes Plates Slitting

Model Number:: TMAX-SL650B
Type:: Electrode Slitting Machine
Dimension(L*W*H):: 20-500mm
Compliance:: CE certificate
Warranty:: Two Year Limited Warranty With Lifetime Support
Payment:: T/T, Credit Card, Paypal, LC, Western Union
Delivery Time:: 3 Days

Email:: [email protected]
WhatsApp:: +8618659217588
WeChat:: 18659217588

Product Description

Cylindrical Battery Semi-Automatic Adjustable Electrode Slitter Machine For Coated Electrodes Plates Slitting

SPECIFICATION

The machine with photoelectric tracking correction system, magnetic powder clutch for winding and unwinding tension control, host frequency, cots on activities is controlled by cylinder can also fit, slitting, can also separate joint or separate cutting, accurate slitting, fast slitting speed and operation and maintenance is convenient etc.

Model	TMAX-SL650B
Size(mm)	2400x1700x1300
Weight(kg)	1000
Power supply	AC220V
Power (kw)	2.2
Slitting speed(m/min)	80
Max slitting size(mm)	650
Min slitting size(mm)	8
Feeding roll diameter(mm)	600
Winding roll diameter(mm)	450
Slitting accuracy(mm)	±0.1mm
