Cylindrical Cell Electrolyte Filling Machine For 18650/26650/32650 Etc Battery Electrolyte Injection

Product Description

1 TMAX-JK-ZYJ-02 Vacuum linear filling machine is used for lithium battery electrolyte injection with high precision and simple operation.

2 This vacuum filling machine can be used for various cylindrical cell cases including CR123,18650 26650, 32650 and AA with changing clamps.

Model	Vacuum Filling Machine TMAX-JK-ZYJ-02
Source voltage	110V-220V AC, 50/60Hz Single Phase
Power	1500W
Warranty	Two years limited and lifetime support
Suitable battery model	18650 / 26650 / 32650, For all kinds of cylindrical battery
Advantages	1 Customized die for all kinds of cylindrical cell types is available according to request 2 Adopt PLC and man-machine interface centralized control, easy operation. 3 Filling speed and times can be set 4 All the parameters such as vacuum time, air input time, filling quantity and battery distance can be adjusted freely. 5 Vacuum box for static control independently
Vacuum filling accuracy	±0.02g
Vacuum filing time	1-10times adjustable
Vacuum filling quantity	0-7g
Vacuum degree	-0.1Mpa
Air supply	0.3-0.6MPa
Working clamps	18650 clamps battery tray 6 rows 8 columns(It can be customized)
