Laboratory Battery Laser Welder For Prismatic Cell Soft Connector Welding&Filling Hole Sealing

Laboratory Battery Laser Welder For Prismatic Cell Soft Connector Welding&Filling Hole Sealing



1、 Equipment Overview

A specialized model designed and developed for the welding of lithium-ion batteries (communication power batteries, energy storage, etc.). With proper clamps, this series of systems can complete the laser welding of aluminum sheets for the liquid injection holes of the prismatic cell case cover and the positive and negative electrode welding of the collector plates of the cover plate.

1. Equipment Outline Drawing (for reference)

2. Workflow:

Manual feeding → Cylinder compression → Press the start button and wait for welding → After welding is completed, the cylinder is released → Manual material collection, cycle operation.

2、 Technical parameters

3、 Process performance

1. Real time processing feedback control performance and waveform control function, achieving ideal welding conditions;

2. The combination design of the galvanometer scanning head enables spot welding and seam welding within the processing range;

3. The gradual in and out function completes the overlap at the beginning and end of the seam welding;

4. The setting of input and output terminals (signals) makes automation easier;

5. Standardized workbench design, simple and flexible debugging of welding fixtures;

6. Strong compatibility of battery models, equipped with universal welding fixtures;

7. PC control operation is convenient, with trajectory teaching function, and easy to use;

8. Equipped with three axes as standard, it can be expanded to four axis linkage to achieve any three-dimensional welding in space;

9. Touch screen human-machine dialogue interface, user-friendly operation, simple and intuitive.

4、 Main component brands
