Lab Vacuum Mixing Machine For Li-ion Battery Research

  • Model Number:

  • Type:

    Mixing Machine
  • Dimension(L*W*H):

  • Net Weight:

    70 lbs
  • Compliance:

    CE certificate
  • Warranty:

    2 Years with lifetime support
  • Delivery Time:

    3 days
contact now

Lab Vacuum Mixing Machine For Li-ion Battery Research

TMAX-SFM-7 is designed to produce coating slurry by mixing small batch of chemical and compound (500 ml Max., upto 30000mPa.s) under vacuum to remove gas bubble and protect sample from oxidation. It has build-in pump which can vacuum the mixing container to -0.08Mpa and the step- less mixing speed at 320rpm. The vibration plate is located at the bottom to remove gas bubble before vacuum mixing and disperse the slurry after mixing. It is excellent for preparing battery electrode paste and various ceramic materials in research lab.



Voltage Input

  1. Single Phase 110VAC or 220VAC ( please choose from product  option bar
  2.  220V AC Power plug is not included. Please click here to order the plug)



Rotary Speed

320 rpm

Mixing Container

  1.  One 150ml stainless steel and one 500ml aluminum container are included.
  2. 100mL aluminum container is available at the related product below.

Vacuum pump

Built in

Vacuum Level

-0.08~0.09 Mpa

Vibration Plate

Vibrating at 1000 Hz


13''L x 12''W x 21''H

Shipping Dimensions

16''L x 15''W x 24''H

Net Weight

70 lbs


CE certified

vacuum mixer

vacuum mixer

vacuum mixer

vacuum mixer

vacuum mixer

vacuum mixer

vacuum mixer


 battery equipment

1.  We supply machines with battery technology support.

2.  We supply full set of lithium battery equipment for lab research, pilot scale research and production line.

1 Standard exported package : Internal anticollision protection, external export wooden box package
2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode
3 Responsible for the damage during shipping process, change the damage part for free
4 Supply with suitable voltage input and power plug according to customer's country requirements.
5 Supply with CO, ECO, FORM A, FORM E and any other original certificate for import custom clearance and tax relief.
