Lab Battery Film Punching Forming Machine For Preparing Pouch Cell Case

Model Number:: TMAX-SCK700
Type:: Punch Forming Machine
Dimension(L*W*H):: 680*500mm
Net Weight:: About 1200kg
Compliance:: CE certificate
Warranty:: Two Year Limited Warranty With Lifetime Support
Payment:: T/T, Credit Card, Paypal, LC, Western Union
Delivery Time:: 3 Days

Email:: [email protected]
WhatsApp:: +8618659217588
WeChat:: 18659217588

Product Description

Lab Battery Film Punching Forming Machine For Preparing Pouch Cell Case

SPECIFICATION

1 TMAX-SCK700 Pouch Forming Machine is used for lithium polymer battery/ pouch cell cup forming in the laboratory and production line of making pouch cell batteries.

2 The machine is used to prepare polymer cases made of Aluminum Laminated Films.

3 This lab aluminum laminated film pouch forming machine is designed with Double start button and Safety grating protection device, and Automatic counting.

Model	TMAX-SCK400	TMAX-SCK700
Source voltage	AC 220V/110V, 50/60HZ
Power	2500W
Warranty	One year limited warranty with lifetime support
Suitable aluminum film thickness	0.1-0.2mm
Air source	0.6-0.8MPa
Mold materials	S136 Die steel
Punching depth	Single kit≤6mm. Double kit≤12mm
Max aluminum film size	400300mm (LW)	680500mm(LW)
Output	500Time/Hour	400Time/Hour
Output pressure	0-5T, Adjustable	0-8T, Adjustable
Dimension(LWH)	7006501850mm	8508502200mm
Weight	About 600kg	About 1200kg
