Pouch Cell Case Punching/Forming Machine for Aluminum-Laminated Films EQ-MSK-PN120

Model Number:: EQ-MSK-PN120
Type:: Pouch Forming Machine
Dimension(L*W*H):: 62mm (L) x 46mm (W) x 3/4/5/6 mm(H)
Net Weight:: 45kg
Compliance:: CE certificate
Warranty:: Two Year Limited Warranty With Lifetime Support
Payment:: T/T, Credit Card, Paypal, LC, Western Union
Delivery Time:: 3 Days

Email:: [email protected]
WhatsApp:: +8618659217588
WeChat:: 18659217588

Product Description

Pouch Cell Case Punching/Forming Machine for Aluminum-Laminated Films EQ-MSK-PN120

MSK-PN120 is a compact gas-driven Aluminum Laminated Films pouch case forming machine for pouch cell fabrication laboratory. To ensure continuity and compatibility for customer's
research, MSK-PN120 fits the electrodes cut by electrode cutting machine. The adjustable depth (spacers set is included in standard package) allows the formed case to fit electrode stacked in
different height.

SPECIFICATIONS:

Features	Pure pneumatic press with adjustable press speed and pressure. No electrical parts.
Standard Die Size	One standard die is included: 62mm (L) x 46mm (W) x 3/4/5/6 mm(H), which perfectly fits the electrodes cut by
Customized Die Size	It can be Customized die
Air Pressure Requirement	0.8 - 1 MPa Air Compressor is not included
Max. Cup Depth to Punch	< 6.0 mm Precision: ±0.05mm
Max. Punching Pressure	1 metric tons
AL Laminated Film	Thickness of Aluminum Laminated Film: 0.10 - 0.20 mm acceptable Please click the picture to the left to order Aluminum Laminated Film.
Warranty	Two Year limited warranty with lifetime support Rusting and damage due to improper storage condition or maintenance is not covered by warranty
Product Dimensions	370mm(L) x 245mm(W) x 336mm(H)
Net Weight	45kg
Die Installation Warning	The tolerance of precision die is very little; Misalignment will result die damage. Following operation manual when installing the die.
