Vacuum Carbon Tube Furnace use of Double Water Sandwich Structure

  • Model Number:

    TMAX-Carbonfurnace1
  • Compliance:

    CE compliant
  • Warranty:

    Two years limited warranty with lifetime technical support
  • Delivery Time:

    14 days
contact now
DESCRIPTION

Vacuum Carbon Tube Furnace use of Double Water Sandwich Structure


     Equipment characteristics

The furnace is a periodic operation type widely used in functional ceramics optical materials carbon composites hard alloy powder metallurgy and other high temperature vacuum conditions for sintering treatment but also in the case of inflatable molding sintering.



·        The structure

1 the furnace the use of double water sandwich structure the inner layer of stainless steel (1Cr18N9Ti) polishing the outer layer of high-quality carbon steel the upper and lower flange welded into a cylindrical structure flange plane set seal groove.  Using "O" ring vacuum seal and set the water cooling device (to prevent the temperature is too high "O" ring aging).  Open with pumping thermocouple infrared holes and so on.

2 the lid the use of double laminated head structure with observation holes shielding locking open the device and water cooling.

3 the bottom the same double-layer water sandwich head structure with electrode extraction device support platform and a water-cooled device.

4 furnace by the steel and steel plate into a box-type structure the furnace placed in the box nice.

5 vacuum system one Taiwan K-150 diffusion pump with cold trap one Taiwan 2X-15 mechanical pump manual high vacuum butterfly valve vacuum pressure gauge (± Pa) inflatable valve bleed valve and vacuum pipe and so on.  Mechanical pump with metal corrugated hose quick connector connection (slow vibration) vacuum measurement using digital composite vacuum gauge.

6 temperature control system the use of controllable silicon temperature control all instruments for the United States Honeywell digital table temperature control with PID regulation over-temperature sound and light alarm function electrical components Schneider brand electric control panel by Siemens standard production  High precision temperature control easy to operate.

7 the gas system the entire system with an inlet a vent can be inflated.

  8 electrical control the use of SCR temperature control with a large current transformer voltage regulator and temperature control instrument temperature control circuit.  Circuit with water over-current over-temperature alarm and protection.

9 water cooling system from a variety of pipeline valves and other related devices with water and sound and light alarm automatically cut off the power function.

10 transformers and connecting cables with the matching transformer and connecting cable.

11 heating element and heat shield heating element using graphite electrode into a cylindrical structure the insulation screen with graphite carbon felt graphite felt (2-layer graphite tube 4-layer carbon and 4-layer graphite felt each  Layer thickness of 10mm or more) good insulation properties heating evenly large radiation heat shock resistance and can quickly heat and cooling.  Insulation layer and heat separation easy maintenance and loading insulation jacket.


CF vacuum carbon tube furnace





Model

TMAX-Carbonfurnace1

Maximum power of the furnace

25KW

Voltage

 380V

Phase

 3 phase

Maximum heating temperature

 2000 degrees

Temperature control model

PID 40 program temperature control

 Heating carbon tube size  (mm)

  Dia130(inner sizeX220

Effective heating size  (mm)

   Dia80X100

 Cavity vacuum (diffuser unit)

< 5X10 -3Pa

Cavity inflation pressure

< 0.15Pa

Boost rate

<4Pa/小时

Break even protection and display

 Yes

Over temperature protection

Yes

Overcurrent protection

Yes

Undervoltage protection (water pressure)

Yes

control precision

+/-  1

 Temperature detection method

 Type B thermocouple or infrared thermometer

  Maximum heating rate

 < 20 degrees/Min

  water-cold vacuum chamber

 Yes

   Observation window size

  Dia 90mm

    Chiller (optional)

CW-6100AH





Vacuum unit



Unit input voltag

380V /220V

Bellows

KF40X1000

Vacuum baffle valv

KF40

  Front machine vacuum pum RVP-6



Power

0.75KW

Voltage

380V

Rotating speed

1450rpm

Air intake diamete

 KF25/KF40

Pump speedL/S

6

Ultimate pressur

4X10 -2Pa

Diffusion pum  TK150

Voltage

220V

Power

1000W

Air intake interface

DN150

outlet interface

DN40

Injection of oil

0.3L

Pumping rateN2

1000L/S



Composite vacuum gauge

ZDF

 Power supply

 220V   55W

control precision

± 1%

Vacuum gauge measurement range

10-5 -10 5 P





1.  We supply machines with battery technology support.

2.  We supply full set of lithium battery equipment for lab research, pilot scale research and production line.




1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

3 Responsible for the damage during the shipping process, will change the damage part for you for free.
